Emergency communications relay tethered drones are an efficient means of communication, providing vital communications support during natural disasters and emergencies. Myuav Technologies, a leading company focusing on innovative tethered drone solutions, has made significant achievements in the field of communication relay drones in recent years.

▶Product Overview
The main function of the tethered power system is to provide safe and reliable power for the UAV to fly for a long period of time. It consists of a tether box and an on-board power supply, in which the tether box contains a winch for retrieval and release, a ground power supply, and a tethered cable.

Endurance: The tethered UAV is powered by a ground generator and connected to the ground emergency communication vehicle through an optoelectronic composite cable to achieve uninterrupted power transmission, guaranteeing 24-hour airborne coverage and providing reliable emergency communication for disaster relief and rescue, field operation, public security and anti-terrorism, and national defence and military industry.

Stable hovering: The tethered UAV flight control system adopts high-precision sensors to accurately measure the UAV's three-dimensional speed, three-dimensional acceleration and three-dimensional angular velocity in real time and carry out attitude and position solving, so that the UAV can still maintain a stable hovering working state under various meteorological environments.

Mobility: Due to its small size and high degree of integration, the tethered UAV can be carried by a small off-road vehicle and quickly arrive at the disaster area or mission area; even if it encounters road obstruction, it can be deployed flexibly by using the UAV's lifting altitude to safeguard the timely functioning of emergency communications.

▶Detailed parameters
▶Drone
Number of rotors: 6 rotors
RTK hovering accuracy: horizontal ≤ 0.5m, vertical ≤ 0.5m
Maximum Task Load: Maximum task load ≥30Kg (excluding the weight of tethered cable) at 200m altitude.
Maximum working altitude ≥3.5KM; maximum wind level ≥6; UAV waterproof and rainproof performance IP65; support for one-key takeoff, one-key return, planning route automatic flight function, low power automatic return, signal loss automatic return, tethered power outage autonomous landing and other functions; operating temperature: -20 ℃ to 50 ℃.

▶Tethered system
●Specialised on-board power supply MP100 - rated output power 10KW, can be fully loaded for a long period of time.
●Tethered base station MJ300 - Tether height Max.210 metres
Main functions: Carrying wireless LAN vehicle station, realising communication relay in complex terrain conditions, and the type of load can be expanded according to the actual situation.

With the advancement of technology, Myuav will continue to dedicate itself to the research and development of higher-performance and more widely-used tethered UAS to promote the development of low-altitude economy and bring more convenient and efficient airborne solutions to various industries.
